17.04.2019

On March 17, 2002, the German-US satellite duo GRACE (Gravity Recovery and Climate Experiment) were launched to map the global gravitational field with unprecedented precision. After all, the mission lasted a good 15 years - more than three times as long as expected. When the two satellites burnt up in the Earth's atmosphere at the end of 2017 and beginning of 2018, respectively, they had recorded the Earth's gravitational field and its changes over time in more than 160 months.

This so-called time-resolved satellite gravimetry makes it possible, among other things, to monitor the terrestrial water cycle, the mass balance of ice sheets and glaciers or sea-level change, and thus to better understand the mechanisms of the global climate system, to assess important climatic trends more precisely and to predict possible consequences.

A review in the journal Nature Climate Change, in which Frank Flechtner, Christoph Reigber, Christoph Dahle and Henryk Dobslaw from the Helmholtz Centre Potsdam German Research Centre for Geosciences GFZ and Ingo Sasgen from the Alfred Wegener Institute, Helmholtz Centre for Polar and Marine Research (AWI) participated, now presents highlights in the field of climate research based on GRACE observations.

Ice sheets and glaciers
GRACE produced the first direct measurement of ice-mass loss from ice sheets and glaciers ever. Previously, it had only been possible to estimate the masses and their changes using indirect methods. Within the first two years of the mission it was already possible to observe clear signals of ice-mass loss in Greenland and Antarctica. The measured data showed that that 60 percent of the total mass-loss is due to enhanced melt production in response to Arctic warming trends, while 40 percent is due to an increase of ice flow into the ocean. According to GRACE data, between April 2002 and June 2017 Greenland lost about 260 billion tons of ice per year, Antarctica about 140 billion tons. In addition to long-term trends, the gravity field data also provide evidence of the direct effects of global climate phenomena such as 'El Niño' on ice sheets and glaciers worldwide.

Terrestrial water storage
Among the most impactful contributions of the GRACE mission has been the unveiling of Earth’s changing freshwater landscape, which has profound implications for water, food and human security. Global estimates of GRACE trends suggest increasing water storage in high and low latitudes, with decreased storage in mid-latitudes. Though the GRACE record is relatively short, this observation of large-scale changes in the global hydrological cycle has been an important early confirmation of the changes predicted by climate models through the twenty-first century.

GRACE data also help to analyse and assess the sea level more accurately, as the storage of freshwater on land is linked to the sea level by various mechanisms. Analyses of GRACE data have enabled the first-ever estimates of groundwater storage changes from space. They confirm excessive rates of groundwater depletion from individual aquifers around the world. The data on terrestrial water storage have also contributed to the validation and calibration of various climate models.

Sea-level change and ocean dynamics
Within this century, sea-level rise could accelerate to 10 millimetres per year – a rate unprecedented during the past 5000 years and a profound and direct consequence of a warming climate. High-precision sea-level measurements have been available since the early 1990s but they only show the absolute sea-level change. In the 25 years between 1993 and 2017, the sea-level rose by an average of 3.1 millimetres per year. To find out how thermal expansion, melting ice and the continental influx of water each affect sea-level, it is necessary to study the water’s mass distribution.

GRACE has shown that 2.5 millimetres of the average annual sea-level rise of 3.8 millimetres between 2005 and 2017 is caused by the inflow of water or other mass and 1.1 millimetres by the thermal expansion of water. Resolving this composition is important for sea-level projections. GRACE data provide a constraint on ocean mass change and thus indirectly on the Earth's energy imbalance, which is a fundamental global metric of climate change. GRACE has shown that most of the warming released by the rise in temperature occurs in the upper 2000 metres of the oceans, which are the most important energy sinks of climate change. GRACE also contributes to a better understanding of the dynamics and impact of ocean currents, in particular for the Arctic Ocean.

Climate service applications
The gravity field data of the GRACE satellites help to improve the United States Drought Monitor. This helps US authorities to react to droughts in a timely and sensible manner. With EGSIEM (European Gravity Service for Improved Emergency Management), the European Union has promoted a service designed to identify regional flood risks as early as possible. Between April and June 2017, test runs with historical flood data took place, showing that the wetness indicators for large river basins determined by GRACE can improve forecasts, for example for the Mississippi or the Danube. Current results also show that GRACE data can be used to more accurately predict the risk of seasonal wildfires.

The GFZ operated the GRACE mission together with the German Aerospace Center (DLR) and on the US side with the NASA Jet Propulsion Laboratory (JPL). In May 2018, the follow-up mission GRACE Follow-on (GRACE-FO) was launched. The first monthly gravity field maps should be available to international users by the end of July this year. Unexpected difficulties delayed the submission of the products. "The reason was the failure of a control unit on the second GRACE-FO satellite," explains Frank Flechtner of GFZ. "This made it necessary to switch to the replacement unit installed for such scenarios. But now, with GRACE-FO, a more than two decades long recording of the mass changes in the system Earth is within reach."

Original study: Teplay, B. D., Watkins, M.M., Flechtner, F., et al., 2019. Contributions of GRACE to understanding climate change. Nature Climate Change. DOI: 10.1038/s41558-019-0456-2

Background:
The weight of water
The greater the mass of an object, the greater its gravitational attraction. For example, the Alps exert a higher gravitational pull than the North German lowlands. When satellites orbit the Earth and fly over a massive region, they accelerate minimally when approaching it and slow down as they fly away.

A tiny part of the gravitation emanating from the Earth is based on water on or near the surface in oceans, rivers, lakes, glaciers and underground. This water reacts to seasons, storms, droughts or other weather effects. GRACE took advantage of the mass displacement of water by recording its effect on the satellite duo that orbited our planet 220 kilometres in a row. Microwaves were used to measure their distance. This distance changed over time due to the mass shift on Earth. From the data, the researchers then calculated monthly maps of the regional changes in the Earth's gravitational pull and the causal changes in the masses on the surface.

Quelle: Helmholtz Centre Potsdam GFZ German Research Centre for Geosciences
